SoundCraft Signature 12 User Manual

10, 12, 12MTK User Manual
4.6: MASTER STEREO OUTPUT
CONSOLE ROUTING > MASTER STEREO OUTPUT
4.6: MASTER STEREO OUTPUT ROUTING
The Master Stereo output is derived from contributions to the Master (MST) Stereo Bus. For Signature
10, all input channels are permanently routed to the MST Bus (post pan/balance). For Signature 12
and 12MTK you can choose to route to the Master Stereo Bus using an input channel’s MST button.

SoundCraft Signature 12 Specifications

General

Number of Channels	12
USB Interface	2-in/2-out
Faders	60mm
Phantom Power	Yes
Type	Analog
Headphone Output	1 x 1/4"
EQ Bands	3-band
Effects	Yes, with Lexicon effects
Inputs - Line	8
Outputs - Main	2 x XLR
Main Outputs	2
Monitor Outputs	1/4"
Weight	14.3 lbs
