5.1.2: STEREO INPUT CONTROLS
CHANNEL CONTROLS > STEREO INPUT CONTROLS
5.1.2: STEREO INPUT CONTROLS
BAL
Adjust stereo balance for this channel
Adjusts the relative levels of the left and right signals for this channel, eectively adjusting the left-right position
of the overall stereo image. For Signature 12 and 12MTK consoles the balance is also adjusted across Group 1 (left)
and 2 (right) when the channel is routed to GRP 1-2.
GRP 1-2
Route the channel output to Group 1 and 2 busses
Signature 12 and 12MTK only. The channel's PAN/BAL or BAL control determines the proportion of the signal
across group pairs.

SoundCraft Signature 12 Specifications

General

Number of Channels	12
USB Interface	2-in/2-out
Faders	60mm
Phantom Power	Yes
Type	Analog
Headphone Output	1 x 1/4"
EQ Bands	3-band
Effects	Yes, with Lexicon effects
Inputs - Line	8
Outputs - Main	2 x XLR
Main Outputs	2
Monitor Outputs	1/4"
Weight	14.3 lbs
