5.4: MASTER STEREO OUTPUT
CHANNEL CONTROLS > MASTER STEREO OUTPUT
5.4: MASTER STEREO OUTPUT
The Master (MST) Stereo Output channel determines
the output level of the main stereo (left and right) mix
from the MST L and MST R physical outputs.
On Signature 12, input channels must be routed to the
Master Stereo Output with their MST buttons.
FADER
Adjust the overall level of the Master Stereo output
INTERVAL MUTE
Mute all channels except 11/12 (Signature 12 and 12MTK) or 9/10 (Signature 10)
A fast way of switching to only the interval or playback source, or similar, without touching any other controls.
Connect the playback device to the Stereo Playback channel (highest numbered stereo channel, RCA inputs).
Engage the INTERVAL MUTE switch when required. All other channels are muted. NOTE: Aux and Group outputs
are still active.

SoundCraft Signature 12 Specifications

General

Number of Channels	12
USB Interface	2-in/2-out
Faders	60mm
Phantom Power	Yes
Type	Analog
Headphone Output	1 x 1/4"
EQ Bands	3-band
Effects	Yes, with Lexicon effects
Inputs - Line	8
Outputs - Main	2 x XLR
Main Outputs	2
Monitor Outputs	1/4"
Weight	14.3 lbs
