SoundCraft Signature 12MTK User Manual

10, 12, 12MTK User Manual
4.2: STEREO INPUT
CONSOLE ROUTING > STEREO INPUT
4.2: STEREO INPUT ROUTING
There are two types of
Stereo input channel.
Thersttwostereo
input channels have
microphone inputs
and can be used as
mono input channels
(odd-numbered input)
if required.
The highest-numbered
Stereo input is a sum of
the line level R inputs
and the stereo USB
input (if present). This
is the playback channel
and works with the IN-
TERVAL MUTE function
for convenient 2-track
playback functionality.
Stereo input channels
have the same routing
options as mono input
channels. Aux bus
contributions from
stereo channels are
made from a sum of the
left and right signals.
Group (GRP 1 and 2)
bus contributions from
(Signature 12 and
12MTK only) are
balanced / panned left
and right to Group 1
and Group 2 respect-
vely. In other words -
fully left would be fully
Group 1.

SoundCraft Signature 12MTK Specifications

General

Type	Analog
Channels	12
Phantom Power	Yes
Computer Connectivity	USB
USB Interface	14-in/12-out
EQ Bands	3-band
Faders	60mm
Aux Sends	3 Aux Sends
Dimensions	420mm x 360mm x 140mm
Outputs - Main	XLR, 1/4" Jack
Outputs - Other	2 Aux
Inputs - Other	2 Hi-Z Inputs
