SoundCraft Signature 12MTK User Manual

10, 12, 12MTK User Manual
7.0: USB OPERATION
USB OPERATION
7.0: USB OPERATION
The Soundcraft Signature consoles use USB 2.0 audio streaming for sending and receiving digital
audio. The Signature 10 and 12 consoles have a two-track USB system while the Signature 12MTK
(Multi-Track) uses a 12-channel system for channel direct inputs and outputs, plus a two-channel
system for the Playback Channel and recording the recording the main LR mix..

SoundCraft Signature 12MTK Specifications

General

Type	Analog
Channels	12
Phantom Power	Yes
Computer Connectivity	USB
USB Interface	14-in/12-out
EQ Bands	3-band
Faders	60mm
Aux Sends	3 Aux Sends
Dimensions	420mm x 360mm x 140mm
Outputs - Main	XLR, 1/4" Jack
Outputs - Other	2 Aux
Inputs - Other	2 Hi-Z Inputs
