SPECIFICATIONS
THD < 0.1%
Signal-to-noise Ratio >100dB
Frequency Response 20Hz to 20 kHz +/- 0.5 dB
Bandwidth 15Hz to 50kHz
Stereo Separation > 90dB
Damping > 200
Input Sensitivity 200 mV - 5.0 V
Input Impedance 12 k ohms
CROSSOVER SPECIFICATIONS (all continuously variable):
2-way
High Pass: 12dB/octave. 60 - 240 Hz
Low Pass: 24dB/octave, 30 - 120 Hz
3-way
Midbass High Pass: 12dB/octave. 60 - 240 Hz
Midbass Low Pass: 12dB/octave. 200 - 800 Hz
Subwoofer Low Pass: 24dB/octave. 30 - 120 Hz
4-way
Tweeter High Pass/Midrange Low Pass: 12dB/octave. 800 - 4 K Hz
Mid High Pass/ Midbass High Pass: 12dB/octave. 200 - 800 Hz
Midrange or Midbass High Pass: 12dB/octave. 60 - 240 Hz
Subwoofer Low Pass: 24dB/octave. 30 - 120 Hz
DIMENSIONS: (W x D x H)
19¨ x 14¨ x 5.5¨
22
SATELLITE CHANNELS
4Ω Stereo 2ΩStereo
(8Ω Bridged) (4Ω Bridged)
12 Volts 14.4Volts
Watts 50W x 4 100W x 4
(100W x 2) (200W x 2)
++
100W x 2 200W x 2
(200W x 1) (400W x 1)
SUBWOOFER CHANNEL
4Ω 2Ω 1Ω
12 14.4 14.4
Volts Volts Volts
High 200W 400W 500W
Power
POWER OUTPUT
