Controls & Functions
5. Subsonic Filter Control
Variable Subsonic Filter (15Hz - 40Hz) :
The Subsonic filter will roll off all of the unwanted frequencies below 15Hz - 40Hz.
This will allow the amplifier to use that wasted power on the audible bandwidth.
6. Bridged Mode Switch
7. Low Level Input RCA jacks
These inputs a re for signa l c a bles from the sourc e. Alwa ys use high qua lity shielded
RC A c a bles.
8. Low Level OUT RCA jacks
The LINE OUT a llows you to build multiple a mplifier systems without ha ving to use splitte r
c ords to distribute the signa l. Now it is simply a ma tter of bringing one set of RC AS into
the first a mplifier, then using the line out RC A ja c ks a s the fee d to the next a mplifier.
7
CONTROLS & FUNCTIONS
7
PCA1000D/1500D/2000D PCA3500D
