CONTROL FUNCTIONS
7. REMOTE
Connect the remote controller to control the subwoofer amplifier volume from the
driver seat location, for ease of adjustment during playing.
8. LEVEL Control
The level control will match the amplifiers sensitivity to the source units signal
voltage. The Operating range is 200mV minimum to 5V maximum. This is NOT a volume
control!
9. Low Pass Filter Control (Mono)
This control is used to select the desired low pass x-over frequency. The frequency
can be adjusted from 40Hz to 220Hz for all bass mono models.
10. Subsonic Filter Control (Mono)
This control can filter out unwanted low frequency from 10Hz (OFF) to 50Hz. This
function will increase the power handling of your woofers.
11. Bass Boost Frequency and Level Control (2-ch)
By adjusting these two knobs, you can boost a wanted frequency to a wanted level.
The center boost frequency is adjustable from 30Hz to 90Hz, the boost level is adjustable
from 0dB to 12dB.
12. X-over mode and frequency Control (4-ch)
These controls allow control over the frequencies played for the front channels.
There is an option for Low Pass, Full Range or High Pass. In LP or HP mode the frequency
range is from 50Hz to 4kHz.
CONTROL
FUNCTIONS
