PERFORMING A CABLE PULL IDENTIFICATION
• Model #: XDTM
• Stock #: 65111501
• Length: 7.50 Inches
• Width: 20.50 Inches
• Height: 10.50 Inches
• Weight: 41 lbs.
i. The first file will be the raw pull data in a comma
delimited text file that can be easily imported into
Microsoft Excel for analysis.
ii. The second is a text file with key pull data summarized.
The summary includes:
1. Peak tension achieved.
2. Time that peak tension was reached.
3. Distance that peak tension occurred.
4. Elapsed time of pull.
5. Total pull distance.
6. Max tension alarm point used during pull.
12. When complete, power off the unit and recharge if needed.
Place in case when storing or transporting.
SPECIFICATIONS
3. POWER BUTTON
SCROLL RIGHT
SCROLL LEFT
INCREASE VALUE
DECREASE VALUE
ENTER/ACCEPT VALUE
4a - ACTIVE/PAUSED
BUTTON
4a - ACTIVE/PAUSED
INDICATOR
1. ROPE PATH
2. USB DRIVE SOCKET
