Soyal AR-331-E - Anti-Passback Functionality; Enable Device; Enable Card User

V220922
AR-331-E/EF
SOYAL
ACCESS CONTROL SYSTEM
- 5 -
Enable device
Access programming mode
→
20 0 or 1 ??? 0 or 1= Enable target unit ( 0=Main Controller Parameter Setting,1=WG Input Port Parameter Setting)
[Please refer to
Compound Command Function List
for details.]
[e.g.] If the AR-331-E/EFset to exit reader, WG Reader set to access reader.
Access programming mode
→
20 0 128
→
20 1 192 [Please refer to fCompound Command Function List for details.]
Enable/Disable auto open zone
Access programming mode
→
20 0 or 1 ??? 0 or 1= Enable target unit ( 0=Main Controller Parameter Setting,1=WG Input Port Parameter Setting)
[Please refer to
Compound Command Function List
for details.]
[e.g.] If the AR-AR-331-E/EFset to Enable aut open zone.
Access programming mode
→
20 0 004 [Please refer to function default value for details.]
[e.g.] If the WG Reader set to Enable aut open door without presenting card.
Access programming mode
→
24 1 128 [Please refer to function default value for details.]
Enable/Disable auto open door without presenting one valid card
Access programming mode
→
24 0 or 1 ??? 0 or 1= Enable target unit(0=Main Controller Parameter Setting,1=WG Input Port Parameter
Setting)
[Please refer to
Compound Command Function List
for details.]
[e.g.] User address from 00152 to 00684 enable the anti-pass-back function: 26 00152 00684 0
Enable card user
Access programming mode
→
26 SSSSS EEEEE P
SSSSS= starting user address; EEEEE= ending user address [P=0 Enable/ P=1 Disable/ P=2 Reset]
[e.g.] AR-331-E/EF(without WG reader), to set second time zone which could be passed only at 9:30am to 4:20pm on Mon, Wed and Fri.
Access programming mode
→
08 10 02 09301620 01010100
→
setting is completed
Setting up access time
Access programming mode
→
08 MW NN HHMMhhmm 7123456H [M=AR-331-E/EF; W=Reader(0=disable,1=enable); NN: 16 sets of
auto-open zone (NN=00~15); HHMMhhmm=Starting time to ending time; 7123456H= 7 days of week + Holiday (F= 0: disable; 1: enable)]
Usually, anti-pass-back is commonly applied to parking areas in order to prevent from multi-entry with one card at a time, or somewhere wants to
monitor not only the access but also exit condition.
Door will remain open after ashing one valid card. When the reader is stand-alone, supporting only 16 sets of auto-open zone by device setting.
Auto-open zone can extend up to unlimited sets by Networking.
Please refer to paragraph Compound Command Function List below to ensure command 20 0 or 1 ??? / 24 0 or 1 ??? will not
reset the functions that already had been changed.
F. Anti-pass-back
G. Auto Open Access (uncontrolled) Time Zone – Automatically Release
H. Lift control
Single oor
[e.g.] User address NO. 45 only can reach the elevator to the 24th oor: 27 00045 24
Access programming mode
→
27 UUUUU LL
UUUU=User Address LL=Floor number (01~64 oor)
Connect with AR-401-IO-0016R to control oors which the user will be able to access.
D. Setting up the password
E. PIN & UID Length setting
Individual PWD (M4/M8)
Card or PIN: Access programming mode
→
12 UUUUU PPPP [e.g. User address: 00001 and PWD: 1234. Input 12 00001 1234 ]
Card and PIN: Access programming mode
→
13 UUUUU PPPP [e.g. User address: 00001 and PWD: 1234. Input 13 00001 1234 ]
Access programming mode
→
42 m n
【m＝PIN code Length 4~8 Digit；n＝ UID Length 2~8 Digit】(4 is default value)
Example:
42 8 4
【PIN code Length 8 Digit；UID Length 4 Digit】
