6 SC-CF & SC-MP Service Manual
Electrical Wiring
Correct wiring of the electrical service box, GFCI box and pack terminal
bloc is essential.
1• Carry out a visual inspection to check for signs of miswiring.
Refer to supplied wiring diagrams.
Call an electrician if necessary.
Electrical Box GFCI Pack Terminal Block
Pack Terminal Block
For 240 VAC systems:
For 120 VAC systems:
L2
N
G
L1
L2
N
G
L1
