SPALDING 881042 - Trigger Mechanism Attachment

20
6.
Insert the bolt (23) through the handle arms (29), vertical tubes (36), and gas strut assembly bracket as shown.
Secure using the nut (18) as shown.
TIGHTEN BOLT (23) IN LOCK NUT (18) UNTIL FLUSH
(EVEN) WITH LOCK NUT’S OUTER EDGE.
WARNING!
18
23
35
36
