Fasten the trigger (7) to the gas strut assembly (21) by using the bolt (12) and nut (55).
NOTE: THE TRIGGER WILL BE BETWEEN THE PLATES OF THE BRACKET AND ABOVE THE BOLT (54).
SQUEEZING THE TRIGGER WILL ALLOW THE RIM HEIGHT TO BE ADJUSTED.
