Assemble the Base
16
C
INSTALL THE POLE ONTO THE BASE
5. Rotate the non-secured ends of the base struts (4 and 5) to align with the mounting holes in the
base.
6. Secure the ends of the base struts (4 and 5) to the base frame using bolts (B1) and lock washers (B7).
IMPORTANT
TIGHTEN ALL COMPONENTS COMPLETELY.
#B1
#B7
#5
#4
