Specialized EPIC EVO - Page 18

15
2
REAR
BRAKE
2nd HOLE CAN BE
DRILLED FOR A REAR
SHIFT OR DROPPER
POST HOUSING
If you’re running either a cable actuated dropper post or mechanical shifting
only, you can either use the 3-hole guide (Fig. 1), or you can complete the
drilling from the back of the closed hole in the 1-hole guide (Fig. 2).
 Use no guide if:
• You’re running a mechanical or wired electronic rear derailleur, a cable actuated dropper post and a
cable actuated rear shock remote lever.
3
REAR
BRAKE
REAR SHIFT, DROPPER
POST AND SHOCK
ACTUATOR
If a cable actuated rear shock remote lever is used, the cable housing will
enter the head tube ICR port and go into the top tube, then exit the top tube
above the rear shock (fig.3).
