4.2. GENERAL SPECIFICATIONS
ITEM PART # SPECIFICATION
HEADSET
S192500021
HDS CANE CREEK,CAA2016,41.8/28.6/FLAT IS52/40 W/AL RACE
SEAL, CROWN RACE FOR MY20 EPIC/EPIC HT SW
SEAT COLLAR S184700003 STC MY18 EPIC SEAT COLLAR 34.9 MM WITH TI BOLT
SEAT COLLAR DIAMETER 34.9mm
SEATPOST DIAMETER 30.9mm
DERAILLEUR HANGER S202600002
HGR SRAM AC UDH DERAILLEUR HANGER AL BLACK (00.7918.089.000)
BOTTOM BRACKET SHELL BSA THREADED 73mm
REAR HUB AXLE S170200003
AXL THROUGH AXLE, JD JD-QR43, 7075-T73 AXLE W/C6801 WASHER,
REAR, 148MM SPACING, 172MM LENGTH, 12MM
REAR TIRE MAX 29 x 2.4”
REAR WHEEL TRAVEL 110mm
SHOCK LENGTH / STROKE 190mm / 40mm
SHOCK SAG 11mm (27.5%)
SHOCK EYELET 8mm ID x 20mm W
MAX FORK TRAVEL 120mm
MIN / MAX CHAINRING
28 - 36t
MIN / MAX REAR BRAKE ROTOR
160 / 180mm
WARNING! Specialized frames are compatible ONLY with forks that have a specific
range of travel. Use of different styled forks or forks with longer travel may result in
catastrophic failure of the frame which may result in serious personal injury or death.
WARNING! While the Epic EVO frame is generally compatible with tires up
to 29 x 2.4, tire dimensions can vary depending on the manufacturer, and
not all forks are designed to accept a larger tire. Always check with the fork
manufacturer regarding required clearances.
CAUTION: Certain chainrings may not have adequate clearance with the
chainstay. Verify spacing and chainline before using it.
4.3. TOOLS REQUIRED
3, 4, 5, 6, 8mm ALLEN (HEX) KEYS BLUE THREADLOCKER (LOCTITE 243)
TORQUE WRENCH (reversible type, for SRAM UDH) GREEN RETAINING COMPOUND (LOCTITE 603)
HIGH PRESSURE SHOCK PUMP CABLE AND HOUSING CUTTERS
HIGH QUALITY GREASE
4.4. BOLT SIZE / TOOLS / TORQUE SPECIFICATIONS
WARNING! Correct tightening force on fasteners (nuts, bolts, screws) on your
bicycle is important for your safety. If too little force is applied, the fastener
may not hold securely. If too much force is applied, the fastener can strip
threads, stretch, deform or break. Either way, incorrect tightening force can
result in component failure, which can cause you to lose control and fall.
Where indicated, ensure that each bolt is torqued to specification. After your
first ride, and consistently thereafter, recheck the tightness of each bolt to
ensure secure attachment of the components. The following is a summary of
torque specifications in this manual:
GENERAL TORQUE SPECS:
LOCATION TOOL TORQUE (in-lbf)
TORQUE (Nm)
SEAT COLLAR 4mm HEX 55 6.2
12MM REAR AXLE 6mm HEX 133 15.0
DERAILLEUR HANGER 8mm HEX 221 25.0
WATER BOTTLE BOSS 3mm HEX 25 2.8
