Specialized EPIC EVO - Bearing Specifications; Spacer;Axle;Bolt Specifications; Shock Mounting; Hardware Specifications

6
BEARING SPECIFICATIONS
QTY PIVOT LOCATION DIMENSION BEARING
A
2 MAIN PIVOT (Chainstay) 12 ID x 24 OD x 6 W 6901V-2RS
B
2 UPPER LINK @ SEAT TUBE BEARING 10 ID x 19 OD x 5 W 6800V-2RS
D
2 UPPER LINK @ EXTENSION BEARING 10 ID x 19 OD x 5 W 6800V-2RS
C
2 UPPER LINK @ SEATSTAY BEARING 10 ID x 19 OD x 5 W 6800V-2RS
SPACER/AXLE/BOLT SPECIFICATIONS
QTY LOCATION / ITEM DIMENSIONS TOOL TORQUE (in-lbf/Nm)
E
2 MAIN PIVOT SPACER 12.1 ID x 19.5 OD x 3 W
F
2 LINK @ SEAT TUBE SPACER 10.1 ID x 16.5 OD x 2 W
H
4 LINK @ EXTENSION SPACER 8 ID x 16.5 OD x 2 W
G
4 LINK @ SEATSTAY SPACER 8 ID x 16.5 OD x 2 W
I
1 MAIN PIVOT AXLE 12 OD x 86 L
J
1 MAIN PIVOT BOLT M8 x 12.2 L 5mm HEX 89 / 10
K
2 LINK @ SEAT TUBE BOLT M10 x 16 L 6mm HEX 89 / 10
L
2 LINK @ EXTENSION AXLE 8 OD x 17.23 L 4mm HEX
M
2 LINK @ EXTENSION BOLT M5 x 8 L 4mm HEX 53 / 6.0
N
2 LINK @ SEATSTAY AXLE 8 OD x 17.23 L 4mm HEX
O
2 LINK @ SEATSTAY BOLT M5 x 8 L 4mm HEX 53 / 6.0
P
1 FORWARD SHOCK EYE AXLE 8 OD x 29.5 L 4mm HEX
Q
1 FORWARD SHOCK EYE BOLT M5 x 8 L 4mm HEX 53 / 6.0
R
2 FORWARD SHOCK EYE WASHER 8.25 ID x 15 OD x 0.3 W
S
1 REAR SHOCK EYE BOLT M8 x 26 L 6mm HEX 213 / 24.0
T
1 REAR SHOCK EYE WASHER 8.2 ID X 13 OD x 0.5 T
SHOCK MOUNTING / HARDWARE SPECIFICATIONS
QTY LOCATION / ITEM DIMENSIONS TOOL TORQUE (in-lbf/Nm)
U
2 FORWARD SHOCK EYE BUSHING SPACER 12.68 ID x 18 OD x 3.45 W
V
2 FORWARD SHOCK EYE BUSHING O-RING 12 ID x 14 OD x 1 W
W
1 FORWARD SHOCK EYE BUSHING 7 ID x 12.71 OD x 19.8 W
X
1 FORWARD SHOCK EYE PIN 12.7 ID x 15 OD x 12.7 W
Y
2 ECCENTRIC FLIP CHIP 15 OD x 8 ID x 6.5 W
