Specialized EPIC - 7 Internal Cable Routing

13
16
SPACER
FOR
TALL BOTTLE
CAGE (LOWER OPTION)
OR SWAT BOX
CAGE
(UPPER OPTION)
 CARBON FRAME: When placing a large water bottle on the seat tube, to provide clearance for the bottle at the
link area, install the supplied water bottle cage spacer between the cage and the seat tube at the upper hole.
7. INTERNAL CABLE ROUTING
Epic frames have an Internal Cable Routing (ICR) port on the drive-side of the head tube to route a telescoping
seatpost down the down tube to the bottom bracket area. Removal of the bottom bracket provides access to the
bottom bracket area of the down tube through ports in the bottom bracket shell to help guide the seatpost housing
up the seat tube.
Follow the same basic procedures for routing the telescoping seatpost cable housing as for the shift and
brake housings.
If you’re running a telescoping seatpost like the Command Post IR, you should refer to the Command
Post IR Adjustable-Height Seatpost Instruction Guide or other dropper post instruction guide, and
complete the installation of the dropper post cable housing before installing any other cable housing.
