HL760 pairing with the laser
Start with bringing the HL760 into pairing mode.
1. Turn on the HL760.
2. Press and hold the (A) and (B) buttons for two seconds simultaneously.
3. The display shows MENU first, then RDIO.
4. Press the (C) button to display the radio mode:
5. Check if MODE LS is shown to connect the HL760 with a laser (LS).
6. If yes, proceed with step 10.
7. If no, press (C) button. Result: the current mode (HL or OF) flashes.
8. Press (A) or (B) button until MODE LS is blinking.
9. Press (C) button to enter MODE LS. Result: MODE LS stops blinking.
10. Press (B) button. Result: Shows „PAIR“.
11. Press (C) button again. Result: Shows „PAIR“ and a rotating bar.
Switch to laser.
12. Make sure laser is turned off.
13. Press and hold (manual button) and press (power button). Result: Battery LED flashes fast.
14. „PAIR OK“ will be displayed. The laser turns back to the standard display.
15. Press (HL760 power button) twice to show the receiver standard display.
16. Result: the receiver display shows the laser and antennna symbol to confirm the radio connection:
A
B
C
or
or
