SpectraPure
®
SYSTEM STARTUP
1. Before installing your ATO, turn the unit on and run it dry for 20
minutes in order to break the pump in.
2. Use 1/4" tubing to connect the Storage Reservoir to the rubber
tube end of the ATO.
NOTE: Be sure the tubing cannot escape from the Storage Reservoir.
3. Push the tubing into the end of the rubber tubing on the pump.
4. Use 1/4" tubing to connect the right angle fitting on the ATO to
the Display Tank. Firmly push the tubing into the quick connect
fitting until it hits the bottom of the fitting.
NOTE: Be sure the tubing cannot escape from the Display Tank.
5. Mount the Sensor Tube Assembly to the side of your Display Tank
or sump. (See diagrams on Page 5.)
SERVICING THE PUMP MODULE:
These instructions apply to ALL SpectraPure Pump Products. It is
recommended that the pump head be inspected and cleaned, or the
tubing replaced per the following procedure. (Refer to images on pages
14-15)
1. If you are just inspecting the pump head, it is not absolutely necessary
to disconnect the two tubings from the head, but it might make this
task easier (Fig. B-1).
2. Use the provided 3/32" Allen Hex Key to remove the three bolts in
the pump head and lift the pump head away from the motor shaft.
(Fig. B-2)
3. Remove the three white rollers from the pump head. (Fig. B-3)
4. If they are dirty, clean the three white rollers, tubing, head and base
plate with a cloth soaked in De-Solv-it
®
(available in most grocery
stores), acetone, or petroleum spirits. Make sure you remove all
gummy deposits, then rinse parts with water and dry. Next, wipe
the motor shaft clean. Be careful not to spill solvents on the plastic
case or it will damage the finish. Keep cleaning fluids away from the
bearing at the base of the motor shaft.
(continued on next page)
