Chapter 1: Module Overview 1-5
User’s Manual Pub. 0300309-01 Rev. A
Environmental Tests
Test Level Limits
ESD immunity
(Performance Criteria B)
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
Radiated RF immunity
(Performance Criteria A)
10 V/M with 200 Hz sine-wave 50% Pulse 100% AM at 900
and at 1890 MHz
10 V/M with 1 kHz sine-wave 80% AM from 80…2000
MHz
10 V/M with 1 kHz sine-wave 80% AM from 2000…6000
MHz
EFT/B immunity
(Performance Criteria B)
Signal Ports:
± 2 kV at 5 kHz for 5 minutes, Criteria B
Power Ports:
± 2 kV at 5 kHz for 5 minutes, Criteria B
Surge transient immunity
(Performance Criteria B)
Signal Ports:
± 2 kV line-earth {CM} at 42 Ω
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
Conducted RF immunity
(Performance Criteria A)
10 V RMS with 1 kHz sine wave 80% AM from 150
kHz…80 MHz on signal and power ports
Magnetic Field
(Performance Criteria A)
30 Arms/m
AC Mains Voltage Dips,
Interruptions and Variations
Follow the 61000-4-11.
Table 1-3. Safety Test Specification Table
Safety Tests
Industry Standards
UL Safety
UL 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use–Part 2-201: Particular
Requirements for Control Equipment (NRAQ, NRAQ7)
cUL CAN/CSA C22.2 No. 61010-1-12 (Safety Requirements for Electrical
Equipment for Measurement, Control,
and Laboratory Use–Part 1: General Requirements)
UL Hazardous
Locations
ULH ANSI/ISA–12.12.01–2007 Nonincendive Electrical Equipment for Use
in Class I, Division 2 Hazardous (Classified) Locations (NRAG)
cULH CSA C22.2 No. 213-M1987–Non-incendive Electrical Equipment for
use in Class I Division 2 Hazardous Locations–March 1987 (NRAG7)
Temp code T4 or better, Pollution degree 2, gas groups a, b, c, and d.
