Chapter 1: Module Overview 1-3
User’s Manual Pub. 0300309-01 Rev. A
For the 2085-OV32-SC, the switch close is between the channel output
pin and the GROUND return pin on the terminal block.
The state of each output channel is displayed on the front panel LEDs.
All outputs have fault tolerance and ESD protection to avoid damage to circuitry
on the board. The modules use 50 VAC working Reinforced Insulation between
the output channels and the backplane, and between the output and the Chassis
GND. 50 V working Basic Insulation is provided for group-to-group isolation.
Each output channel can be directly controlled via Rockwell-provided Connected
Component Workbench (CCW) software for Micro850 and Micro870 family
controllers once the controller is in run mode. Pre-channel configuration is not
required.
The module is tested before shipping. After installation, during startup, devices
begin operation in a useable condition without a requirement for pre-channel
configuration. The module begins operation with all outputs off. The module
normally requires no further user intervention. However, if the module
experiences a hard fault condition, you may need to cycle power or pull the
module from the rack.
Output Specifications
The 2085-OX32-SC modules have the following output specifications:
Table 1-1. Output/Performance/Environmental Requirements
Output Description
Value
Operating Temperature
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
Storage/Non-Operating
Temperature
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
Operating Humidity
5% to 95%, non-condensing
Storage/Non-Operating Humidity
5% to 85%, non-condensing
Vibration/Operating
10 Hz to 500 Hz, 2 G, 0.030 max peak-to-peak
Operating Shock
25 G, peak acceleration, 11 ms pulse, half sine
Storage/Non-Operating Shock
25 G peak acceleration, (35 G for panel mount), 11 ms pulse,
half sine
Pollution Level
Meets Pollution Degree 2 requirements.
Outputs per module
32
12/24 VDC customer supply
voltage
10.5 VDC minimum, 30 VDC maximum
ON-state voltage
10 VDC minimum ON under all conditions
24 VDC nominal under all conditions
30 VDC maximum
ON-State Voltage Drop
Less than 0.5 VDC maximum
ON-state current
1 mA minimum at 10 VDC
0.5 A maximum steady state (8 A per channel group)
