Spectrum Controls Micro800 Series - Plc Interfaces; Connection Types and Assembly Sizes; Output Variable Table

Chapter 3: Configuring the Micro800 Expansion I/O 2085-OX32-SC Using CCW 3-9
User’s Manual Pub. 0300309-01 Rev. A
PLC Interfaces
The 2085 platform stores the following values in the Vendor ID, Product_Type,
Product_Code, Series_Rev, and Mod_Features arrays:
Parameter
OV32-SC
OB32-SC
Vendor ID
58 (Spectrum Controls)
58 (Spectrum Controls)
Product Type
7 (Discrete)
7 (Discrete)
Product Code
116
115
Series Rev
A
A
Module Catalog String
2085-OV32-SC
2085-OB32-SC
3.5.1 Connection Types and Assembly Sizes
The size of each assembly is listed in the table below. Each word takes 2 bytes:
Table
Size (words)
Notes
Configuration
0
Module does not require a configuration
Input
3
Output
2
3.5.2 Output Variable Table
The read-only status variable is located on the CCW Global Variables tab in
visual checkbox format, and in _IO_Xx_ST_yy string format, where:
• x represents the expansion slot number 1…3 for the Micro850 controller
and slot number 1…8 for the Micro870 controller
• yy represents the generic number from 00 to 47.
Channel Status (CCW Var: _IO_Xx_ST_31:00)
Channel status variable is a replica of the reading from FPGA responses.
Whenever any channel control is enabled by the user during RUN mode, the
corresponding channel status variable is also checked as enabled.
Module Status (CCW Var: _IO_Xx_ST_47:32)
The module status variables used in this range are reserved for indicating
different module behaviors as listed below:
CCW Var Index
Bit
Name
Description
_IO_Xx_ST_32
0
FPGA
FPGA Fault
When enabled, indicates there is a module communication
failure over to the FPGA chip. This is a hardware fault.
_IO_Xx_ST_33
1
BO
Module Power Brownout
When enabled, indicates there is a power supply failure to the
module microprocessor and FPGA. This is a hardware fault.
_IO_Xx_ST_39:34
7:2
Not Used
Variables marked as Not Used remain disabled.
