1-8 Chapter 1: Module Overview
User’s Manual Pub. 0300309-01 Rev. A
Module
Power
Supply
OUT-x
POWER 0
GND 0
Backplane
ASIC
Backplane
Communication
.
.
x16
channels
50VAC
Working
Reinforced
Isolation
5V DC
24V DC
(used by backplane
circuitry)
Status
Indicators
RTB pins
2085 Backplane
Isolation
x16
50VAC Working Basic
Isolation Between
Channel Groups
Output
Circuitry
x16
OUT-x
.
.
x16
channels
Isolation
x16
Output
Circuitry
x16
POWER 1
GND 1
Channel Group 0
Channel Group 1
Transient and
Reverse
Voltage
Protection
Inductive
Kickback
Suppression
x16
Inductive
Kickback
Suppression
x16
Transient and
Reverse
Voltage
Protection
FPGA
Processor
