9
The 2000-Series data logger does not have a button or
switch for powering up and down. Instead, the device is
operational whenever the batteries are installed. The log-
gers are shipped with default logging settings that can be
modified with SpecWare software (see SpecWare User’s
Guide for details). Once the logger is configured, it will
retain those settings even after the battery is removed or
replaced.
One new feature of the WatchDog 2000-Series loggers is
that they do not need to be relaunched after being down-
loaded. This allows greater flexibility for loggers that are
accessed by multiple users. Although, the logger stores
data on an interval set in SpecWare, the sensor readings
displayed on the LCD are refreshed every 20 seconds.
The 2000-Series data loggers are configured in the
WatchDog Manager screen of SpecWare software. Re-
member to identify the WatchDog type as 2000-series.
Configuring the
Data Logger
