SPEKTRUM DX8G2 • TRANSMITTER INSTRUCTION MANUAL
EN
Function
1
Antenna
2
Speaker Grill
3
R Knob
4
Switch H
5
Switch G
Switch F
7
Throttle/Aileron Stick
(Mode 1)
Elevator/Aileron Stick
(Mode 2)
Throttle/Rudder Stick
(Mode 3)
Elevator/Rudder Stick
(Mode 4)
Function
8
Elevator Trim (Mode 2, 4)
Throttle Trim (Mode 1, 3)
9
Aileron Trim (Mode 1,2)
Rudder Trim (Mode 3,4)
10
Scroll wheel
Right Side Grip
12
On/OffSwitch
13
LCD
14
Clear Button
15
Back Button
16
SDCardOpening
Function
17
left Side Grip
Neck Strap Mount
19
Rudder Trim (Mode 1,2)
Aileron Trim (Mode 3,4)
20
Elevator Trim (Mode 1,3)
Throttle Trim (Mode 2,4)
21
Elevator/Rudder Stick
(Mode 1)
Throttle/Rudder Stick
(Mode 2)
Elevator/Aileron Stick
(Mode 3)
Throttle/Aileron Stick
(Mode 4)
Function
22
Switch C
23
Switch B
24
Switch A
25
Switch D
26
Bind/Switch I
27
LED
The transmitter comes with a thin,
clear plastic film applied to some
front panels for protection during
shipping. Humidity and use may
cause this film to come off. Carefully
remove this film as desired.
TRANSMITTER FUNCTIONS
4
20
19
18
21
22
23
24
1
5
6
7
9
8
11
12
13
14
15
16
17
25
26
27
2
10
11
18
3
6
