Speed Queen TMB796C - Installation; Pre-Installation Inspection

Specifications and Dimensions
M414905
14
© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT
Electrical Connection Locations
TMB813N
TMB813N
GAS AND STEAM ELECTRIC
A
B
B
A
Models A B
Gas and Steam
9.5 in.
(241 mm)
63.5 in.
(1613 mm)
Electric
19 in.
(483 mm)
64 in.
(1626 mm)
NOTE: These figures are approximate dimensions only.
