Tabl e 1
Burner orifice information at 0-2000 feet (0-600 meters)
altitude.
N/A = Part no longer available.
* For Natural Gas, Group E+ applications, convert using
L.P. Gas model and replace burner orifice(s).
** For L.P. Gas, Group B/P with 50 mbar supply pressure,
convert using Natural Gas model, M411334 regulator
spring kit and burner orifice(s).
Country
Code
Gas Type Group
Supply
Pressure,
mbar
Burner
Orifice
Pressure,
mbar
Capacity/
Model
Diameter,
mm
Quantity
Burner
Orifice
Part No.
DK/NO/
SE/FI/CZ/
EE/LV/LT/
SI/SK
Natural Gas H 20 8.9 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas B/P 30 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
DE**
Natural Gas E 20 8.9 050
075
3.7
3.6
2
3
M401000
M401014
LL 25 12.6 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas B/P 30 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
B/P 50 28.5 050
075
2.1
2.0
2
3
M401003
M400999
NL
Natural Gas L 25 12.6 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas B/P 30 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
BE/FR*
Natural Gas E+ 20/25 No Governor 050
075
3.0
2.9
2
3
M401017
N/A
L.P. Gas + 28/37 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
GB/IE/PT/
ES/IT/GR/
LU/CH
Natural Gas H 20 8.9 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas + 28/37 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
AT**
Natural Gas H 20 8.9 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas B/P 50 28.5 050
075
2.1
2.0
2
3
M401003
M400999
CY/IS/MT
L.P. Gas B/P 30 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
HU
Natural Gas H 25 8.9 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas B/P 30 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
PL
Natural Gas H 20 8.9 050
075
3.7
3.6
2
3
M401000
M401014
L.P. Gas 3P 37 No Governor 050
075
2.1
2.0
2
3
M401003
M400999
