101501-565 Rev C Page 3 of 58
WARNING
THIS EQUIPMENT GENERATES DANGEROUS VOLTAGES THAT MAY BE FATAL.
PROPER GROUNDING OF ALL HIGH VOLTAGE EQUIPMENT IS ESSENTIAL.SEE ST
OWNERS MANUAL FOR PROPER GROUNDING TECHNIQUE AND SAFETY
PRECAUTIONS BEFORE APPLING AC INPUT POWER TO THE ST UNIT.
TO PREVENT DAMAGE TO THE HOST COMPUTER THE COMPUTER SHOULD BE
GROUNDED TO THE SAME GROUND AS THE UUT.
1.0 SCOPE
This document applies to the communications interfaces on the ST, assembly
460231.
2.0 FUNCTIONAL DESCRIPTION
The ST provides 3 different types of digital communications interfaces:
DB-50F Digital Breakout on JB1
Ethernet (10/100-Base-T) on JB9
3.0 GETTING STARTED - INTERFACE WIRING AND PIN-OUTS
3.1 RS-232 INTERFACE
The RS-232 interface has the following attributes:
115.2K bits per second
No Parity
8 Data Bits
1 Stop Bit
No handshaking
Included in DB-50F Digital Breakout
The pinout of the DB-50F connector is:
