101501-565 Rev C Page 6 of 58
board via Ethernet: the first is to directly cable between the host and the
ST board, and the second is through the use of a switch, hub, or network.
A direct connection requires a non-standard cable where the wires are not
run straight through. Please refer to the two cable ends shown below in
figure 4.
Figure 4 – Crossover Cable for Direct Connection
A standard connection through a hub, switch, or network uses a standard
CAT5 patch cable. Please refer to the two cable ends shown below in
figure 5
Figure 5 – Standard Straight Through Cable – Standard CAT5 Patch
4.0 GETTING STARTED – SOFTWARE
The following sections detail how to create software to interface to the ST
communications interfaces.
