101501-565 Rev C Page 16 of 58
responses only. Commands using a simple response will use the <$> character
(ASCII 0x24) as a “Success” response or a single character error code. These
will be seven ASCII characters in length.
Response Name <CMD> Response
Request kV Setpoint 14 10 ASCII
Request mA Setpoint 15 10 ASCII
Request Misc. Analog Readbacks 20 21 – 45 ASCII
Request Status 22 37 ASCII
Request Software Version 23 22 ASCII
Request Model Number 26 7 – 21 ASCII
Request User Configs 27 9 – 17 ASCII
Request Unit Scaling 28 9 – 14 ASCII
Request FPGA Version 43 22 ASCII
Request kV monitor 60 7 – 10 ASCII
Request mA monitor 61 7 – 10 ASCII
Request Slave Faults 68 31 ASCII
Request System Voltages 69 45 ASCII
