SPHINX Myth 5
11
7. CARE AND MAINTENANCE
Clean the exterior with a soft, lint-free, anti-static
cloth. Do not use force while wiping the surface.
To remove difficult stains use a few drops of
detergent on a moist cloth, sweep carefully and
wipe dry afterwards.
If some scratching occurs, please first consult your
Sphinx dealer. He can give you advice about
possible solutions.
Do not use polishing or cleaning agents: they
may damage the sensitive acrylic finish.
Do not use aerosol cleaning agents.
Most contain solvents which might actively react
and damage the acrylic finish.
8. TECHNICAL SPECIFICATIONS
Bandwidth 10 - 190,000 Hz (+0/-3 dB)
Phase response error <1° (from 0 - 20,000 Hz)
Gain 40.5 dB max. (102.3 times)
Minimum Power Output (1 - 20.000 Hz)
>2x 74 W into 8 Ω (18.7 dBW), THD <0.01%
>2x 115 W into 4 Ω (20.6 dBW), THD <0.01%
>2x 144 W into 2 Ω (21.6 dBW), THD <0.01%
Output voltage / current, max. 23 V / 20 A
THD+N (IHF-A) <0.006% (2
nd
harm., 10 - 20,000 Hz)
IMD <0.030%
S/N ratio (IHF-A) >95 dB
Channel separation >68 dB (1 - 20,000 Hz)
Slew rate >24 V/µs
Damping factor >650 (1 - 1,000 Hz)
Inputs
cinch, unbalanced 1x Line 2, 1x Line 1, 1x CD, 1x Tuner, 1x Tape
level, nominal 1.25 V
impedance
20 kΩ
Outputs
cinch 1x Tape
headphones 1x 6.3 mm stereo jack, adjustable level
clamp 1x loudspeaker L, 1x loudspeaker R
Supply capacitance 35,200 µF total
Power consumption 600 W max.
Dimensions (h x w x d) 73 x 434 x 350 mm
Weight 8 kg
This unit conforms to the EMC interference regulations from the EU and to the CE standards.
This unit complies with safety regulation VDE 0860 and thus with international safety regulation IEC 65.
Technical specifications can be changed by SPHINX without prior notice if technical developments make this
necessary.
©1999 Audioscript BV
