SPIERINGS AT4 - Differential Oil Change

USER MANUAL SPIERINGS TRUCK AT4
AT4-EN-041115.doc
5-7
5.3.3. Differential oil change
Change the oil in the differentials every year during the yearly maintenance service at
normal working conditions.
Caution!
The differentials and oil are hot after driving the truck for a while.
1. Make sure the truck stands on a horizontally flat base.
2. Drain the oil through drain hole (A) concerning axle 2 and 4.
(Picture 5-7)
3. Reinstall the drain plug.
4.
Fill the differentials with approx. 11 litre oil till the oil level reaches
the rim. (B) Check the level after a while and refill if necessary.
Picture 5-7
Two oil drains (A) are used concerning axle 3. (Picture 5-8)
1. Reinstall the drain plugs.
2.
Fill the differentials with approx. 13 liter oil till the oil level reaches
the rim. (B)
3. Check the level after a while and refill if necessary.
Picture 5-8
