7.3. Batteries
7.3.1. Check the batteries
Check the batteries of the truck every two months.
Caution!
Battery acid is harmful for human and environment. Be very careful with it!
The batteries must be checked on the following points:
• Is the fluid level still acceptable (Fill it up with distilled water when necessary)
• Is there no cable wear
• Are the battery clamps still attached on the right way
• Are the batteries still attached on the right way
• Do the batteries need to be recharged
7.3.2. Recharging the batteries
You need a charging device and a charging cable for recharging the batteries.
If you use a quick-charger, all battery cables must be disconnected in order to prevent damage to electronic
components.
1. Be sure the engine is not running. (Remove the ignition key from the ignition slot)
2. Connect a cable on the batteries and the charger.
3. Switch on the charger device.
4. First switch off the charger device after charging the batteries.
5. Remove the cable.
6. Start the engine and leave it for several minutes.
7.3.3. Replacing batteries
We advise to replace the batteries when the engine will start difficulty. (The batteries must be fully recharged.)
Use new batteries with the same brand and dimensions.
1. Be sure the engine is not running. (Remove the
ignition key from the ignition slot)
2. First remove the battery clamp (2) at the “-” poles.
Next those on the “+” poles. (Picture 7-1)
3. Remove the battery-holder (3).
4. Remove the old batteries (1) and place the new
ones.
5. Reinstall the battery-holder.
6. First connect the battery clamp at the “+” poles.
Next those on the “-” poles. (Be sure to tighten
them well)
7. Use Vaseline to grease the poles.
8. Start the engine and leave it for several minutes.
Picture 7-1
