Spirax Sarco AEL3 Series User Manual

IM-P344-01 CTLS Issue 4
IM-P344-01 CTLS Issue 4
8
9
AEL3 Electric Linear Actuators AEL3 Electric Linear Actuators
IP66
EN 60529
5-95%RH
EN 60730
Software
A
III
IP66
EN 60529
5-95%RH
EN 60730
Software
A
III
M
44570Y
54570Y
IP66
EN 60529
5-95%RH
EN 60730
Software
A
III
3. Installation
Only actuators without
accessories
Fig. 1
Warning label
M16 x 1.5 Gland nut
M20 x 1.5 Gland nut
Adaptor
Stroke indicator
clips
3.1 Location
The actuator should be mounted above the valve with sufficient space to remove the terminal cover and
general ease of access. When selecting the location, make sure that the actuator is not exposed to an
ambient temperature exceeding the range -10°C to + 55°C. Humidity <95%. The actuator is rated at IP66.
Warning
Prevent access by non technical personnel!
Items supplied loose
1 off M16 x 1.5 Gland nut
1 off M20 x 1.5 Gland nut
1 off adaptor
1 off warning label
2 off stroke indicator clips
Fig. 2
