IM-P344-01 CTLS Issue 4
IM-P344-01 CTLS Issue 4
14
15
AEL3 Electric Linear Actuators AEL3 Electric Linear Actuators
45˚
2
3
M
A
= 10 Nm
1
4
5
2
1
2
1
4
4
45˚
2
3
M
A
= 10 Nm
1
4
5
2
1
2
1
4
4
55
°C
-10
131
°F
-4
60
°C
-10
140
°F
-4
130
°C
0
266
°F
32
110
°C
0
231
°F
32
Fig. 9
AEL3R
AEL3X
click
OK
AEL3E
Manual Auto
OR
9. Ensure handle is folded back against the actuator.
When mounting an actuator on a valve, never drive the actuator electrically, instead use the handle.
8. For AEL3R and AEL3X - use the handle to lower the actuator spindle until the clamp tightens over
the adaptor.
For AEL3E - fold the handle back to the home position in the actuator head and the spindle will lower
automatically.
Fig. 10
