Spirax Sarco AEL7 Series User Manual

IM-P713-01 CTLS Issue 1
17
AEL7 Series Electric actuator
Table 5 Thread Engagement and Yoke Kit – Hiter S85 / S1000 2-port
Valve Model Ø (") Thread Engagement (mm)
08-18-58-68-02-12-52-62
0.5 26
0.75 25
1.0 25
1.5 14
01-11-51-61-21-71 Full Bore
1 32
1.5 18
01-11-51-61-21-71 Red. Bore 1.5 24
08-18-58-68
2.0
18
01-11-51-61-21-71 Full Bore 43
01-11-51-61-21-71 Red. Bore 33
02-12-52-62 38
08-18-58-68-02-12-52-62
3.0
45
01-11-51-61-21-71 Full Bore 47
01-11-51-61-21-71 Red. 32
08-18-58-68-02-12-52-62
4.0
26
01-11-51-61-21-71 Full Bore 27
01-11-51-61-21-71 Red. Bore 23
51-61-71 - Stroke 2" 6.0 58
51-61-71 - Stroke 3" 6.0 47
51-61-71 - Stroke 4" 6.0 96
51-61-71 - Stroke 2" 8.0 52
51-61-71 - Stroke 4" 8.0 52
