IM-P713-01 CTLS Issue 1
16
AEL7 Series Electric actuator
Table 3 Thread Engagement – Spira-trol™ 2-port
Actuator
Thrust
Spira-trol™ J, K & L 2-Port Valves
DN15-50 DN65-100 DN125+
1.2 kN
12 mm
1
n/a
n/a
2.0 kN
19 mm
2
4.0 kN
6.0 kN
8.0 kN
12.0 kN
15.0 kN
20.0 kN n/a 19 mm
3
30 mm
1
DN15-50 J Series Requires AEL7XJ01 extended adapter
2
DN65-100 J Series Requires AEL7XJ02 extended adapter
3
Requires AEL7XM12 M12 adapter
Table 4 Thread Engagement – QL 3-port
Actuator
Thrust
QL 3-Port Valves
DN15-50 DN65-100 DN125+
1.2 kN
12 mm
n/a
n/a
2.0 kN
14 mm
4.0 kN
6.0 kN
8.0 kN
12.0 kN
15.0 kN 18 mm
20.0 kN n/a 18 mm
1
27 mm
2
1
Requires AEL7XM12 adapter
2
Requires AEL7XQ18 adapter
