SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
Contents
1. General information
4
1.1 General information and instructions
1.2 Warnings
1.3 Intended use
51.4 Improper use
1.5 Warranty provisions
2. Operation
6
2.1 Safety instructions
2.2 Parameterization of the device
2.3 Description of symbols
7
2.4 Operating button functions
2.5 Menu levels
8
2.6 operating modes
2.7 Inhibiting operation 11
3. Configuration
12
3.1 General information
3.2 Example
3.3 4.20mA and 4-20mA HART parameter descriptions (SP7-10 and SP7-20) 13
3.4 HART parameter overview (Graphic) 17
3.5 Parameter group 1: Standard 18
3.6 Parameter group 2: Setpoint 22
3.7 Parameter group 3: Operating range 26
3.8 Parameter group 4: Messages 28
3.9 Parameter group 5: Alarms 31
3.10 Parameter group 6: Manual adjustment 33
3.11 Parameter group 7: Control parameters 37
3.12 Parameter group 8: Analog output 44
3.13 Parameter group 9: digital output 47
3.14 Parameter group 10: digital input 49
3.15 Parameter group 11: Safe position 50
3.16 Profibus PA and Foundation Fieldbus parameter descriptions (SP7-11, SP7-12 and SP7-21, SP7-22) - PROFIBUS PA
and Foundation Fieldbus parameter overview
53
3.17 Profibus PA and Foundation Fieldbus parameter descriptions (SP7-11, SP7-12 and SP7-21, SP7-22) 54
3.18 Specific parameters for digital BUS communication versions only: - P1.5 ADRESS – Bus Address (PROFIBUS PA
version only)
55
3.19 P7.4 GOPULSE^ Go pulse (up)
56
3.20 P7.5 GOPULSEv Go pulse (down)
