27
IM-S51-07 CTLS Issue 1
SP7-10, SP7-11, SP7-12 and SP7-20, SP7-21, SP7-22 Parameterization
With this parameter you can assign the zero position of the display to the zero position of the valves and fittings. It also allows you to
select the direction of rotation of the sensor shaft (looking at the open housing).
NOTE
Normally, the zero position is determined automatically and saved during standard Autoadjust.
Linear actuators counterclockwise
Rotary actuators clockwise
Selection
CLOCKW Limit stop reached turning clockwise
CTCLOCKW Limit stop reached turning counterclockwise
3.7.2 MAX_RGE – Operating range max.
The working range can be configured to be smaller than the maximum mechanical working range.
The setpoint range always refers to the configured working range. Use this parameter to specify the upper limit of the working range
CAUTION
This function is only active in control mode.
In the event of a power supply failure (electric or pneumatic), and in manual mode, the mechanical end
positions are approached
- Do not reach into the adjustment mechanism.
NOTE
The operating range must be greater than 10% of the sensor range.
NOTE
The display of the positioner in operating modes 1.0 through 1.2 always refers to the configured working range
and indicates the position in %.
3.7.3 ZERO_POS – Zero position
