m e te r
METER
CONFIGURATION
See section 17.1.4
To configure the analogue meter to
indicate any one of the parameters
listed.
This is only applicable to SX90
controllers.
OFF
Meter display disabled Conf
HEAT
Heat Output demand
COOL
Cool output demand
w.sp
Working setpoint
pV
Process value
Op
Heat output demand
C.OP
Cool output demand
err
Error (SP – PV)
AmPs
Amps Not applicable
to the SX
series
LCur
Load current
PPOS
Pot position
P ass. c
FEATURE
PASSCODE
To select chargeable features
Contact your supplier.
See also section 17.1.5.
Conf
P ass. 2
FEATURE
PASSCODE
Conf
la n g u
LANGUAGE Alarm messages are shown in the
selected language.
Scrolling Parameter descriptions are
always shown in English.
Eng
English Conf
Fre
French
spa
Spanish
Ita
Italian
ger
German
17.1.1 Home Display Configuration
The upper display always shows PV, the lower display is configurable.
Std
In automatic control the lower display shows setpoint. In manual mode output power is shown.
OP
Output power is shown in both automatic and manual modes.
Tr
Timer time remaining
ELAP
Timer elapsed time
AL1
First configured alarm setpoint
CLr
Blank display
Tmr
The display shows setpoint while the timer is not running and time remaining when the timer is active.
t.sp
The display shows target setpoint so that the target for a ramp may be viewed rather than the current working setpoint
no.pv
The upper display is blank
Stby
The upper display blanks when the controller is in standby mode
17.1.2 Edit keys locked.
Parameters cannot be changed but viewed only. However, it is possible to run, hold and reset timer and acknowledge alarms.
17.1.3 Mode key locked.
Timer run, hold, reset and Auto/Manual cannot be operated from the Mode key.
The following sections in this manual describe the parameters associated with each subject. The general format of these sections is
a description of the subject, followed by the table of all parameters to be found in the list, followed by an example of how to
configure or set up parameters.
