IM-P192-02 MI Issue 2 25

Fig. 21 TVA with EIA 485 (RS485) Communications wiring diagram

Power supply 24 Vdc (19 - 28v) 50 mA maximum

GND data

B - data

A + data

Note: Do not reconnect loop

power supply to these terminals

when RS485 board fitted.
