IM-P146-01 CMGT Issue 4
6
2.2 Sizes and pipe connections
The UFT32 can be fitted to a variety of pipeline connectors including:
PC10HP Straight connector ASME 600 (TI-P128-10)
PC20 Straight connector with 'Y' type strainer ASME 300 (TI-P128-15)
IPC21 Straight connector with 'Y' type strainer and integral
Spiratec sensor
ASME 300 (TI-P128-15)
PC3 _ Straight connector with one piston isolation valve ASME 600 (TI-P128-02)
PC4 _ Straight connector with two piston isolation valves ASME 600 (TI-P128-03)
ST S17.2 Steam trap station (TI-P128-22)
See the relevant Technical Information sheet as listed above for details of the connections available for
each pipeline connector.
2.1 General description
The UFT32 is an austenitic stainless steel maintenance free sealed ball float steam trap with an integral
automatic air venting facility. It is designed for differential steam pressures up to 32 bar.
When installed with a suitable pipeline connector the UFT32 can easily and simply be removed without
breaking into the pipeline, thus speeding up trap replacement with minimal system downtime. Pipeline
connectors are available with screwed, socket weld and flanged end connections.
Standards
The body to cover welded joint complies with ASME Section IX and BS/EN 288.
This product fully complies with the requirements of the Pressure Equipment Directive (PED).
Certification
This product is available with certification to EN 10204 3.1.
Note: All certification/inspection requirements must be stated at the time of order placement.
Note:
For additional information see the following Technical Information Sheet: UFT32 TI-P146-05.
2. General product information
