8
FIRSTTIME USE
Fire Hazard
Never place items in the washer that are dampened
with gasoline or other flammable fluids.
No washer can completely remove oil.
Do not dry anything that has ever had any type of oil on
it (including cooking oils).
Doing so can result in death, explosion, or fire.
Once the appliance has been installed, and before it is used for the rst time,
run a “Clean Washer ” cycle with liquid chlorine bleach and no laundry.
DAILY USE
Prepare the laundry by following the suggestions appearing under the
“TIPS AND SUGGESTIONS” section.
- Press the ON/OFF button .
- Open the door. Load the laundry while making sure not to exceed the
maximum load quantity indicated in the wash cycle table.
- Pull out the detergent dispenser drawer and pour the detergent into the relevant
compartments, as described in the “DETERGENT DISPENSER DRAWER” section.
- Close the door.
- The machine automatically displays the default temperature and spin
speed values for the selected cycle, or the most recently used settings for
that specic cycle.
- Select the desired wash or dry cycle.
- Select the desired options.
- Press and hold the START/PAUSE button to start the wash.
PAUSING A CYCLE
To pause the wash cycle, press the START/PAUSE button again. To start
the wash cycle from the point at which it was interrupted, press and hold
the START/PAUSE button again.
OPENING THE DOOR, IF NECESSARY
Shortly after a cycle starts, the symbol turns on to signal that the door
cannot be opened. While a wash cycle is running, the door remains
locked. To open the door while a cycle is under way, for example, to add
or remove garments, press the START/PAUSE button to pause the
cycle. If the symbol is not lit, the door may be opened. Press and hold
the START/PAUSE button again to continue the cycle.
CHANGING A RUNNING WASH CYCLE
To change a wash cycle while it is in progress, pause the washer-dryer using
the START/PAUSE button, then select the desired cycle and press and
hold the START/PAUSE button again.
To cancel a cycle that has already begun, press and hold the ON/OFF
button. The cycle will be stopped and the machine will drain any
remaining water in the drum, then shut o.
AT THE END OF THE WASH CYCLE
This will be indicated by the word “ ” on the display; when the
symbol switches o, the door may be opened. Open the door, unload the
laundry and switch o the machine. If you do not press ON/OFF button,
the washer-dryer will switch o automatically after about 15 minutes.
OPTIONS
- If the selected option is not compatible with the set wash cycle, the
indicator light will ash accompanied by a buzzer and the option will
not be activated.
- If the selected option is not compatible with another previously
selected option, the indicator light will ash accompanied by a buzzer
and the option will not be activated.
Super Wash
This option lengthens the cycle and uses more water, oering a high-
performance wash.
Delay Start
To set a delayed start for the selected cycle, press the corresponding
button repeatedly until the desired delay period is reached. When this
option has been activated, the symbol lights up on the display. To
remove the delayed start setting, press the button until “OFF” appears on
the display.
Temperature
Each wash cycle has a pre-dened temperature. To modify the
temperature, press the “ Temp” button.
The temperature has 4 selections: Cold - Lukewarm - Warm - Hot.
Spin
Each wash cycle has a pre-dened spin speed. To
modify the spin speed, press the “ Spin” button. The
value will appear on the display.
The spin speed may be adjusted, or the spin cycle can be excluded altogether by
turning OFF all leds.
Prewash
This option performs an additional wash phase with cold water. Add an
additional dose of detergent to the Prewash compartment if using this
option. If this option is used, liquid chlorine bleach cannot be added
TIPS AND SUGGESTIONS
When doing a wash + dry cycle:
The washer capacity is greater than the dryer capacity. Between the wash
cycle and the dry cycle, remove some clothes if needed so that the drum is
no more than half full, for best performance. This will allow more airow
during the dry cycle.
Divide the laundry according to:
Type of fabric (cotton, mixed bres, synthetics, wool, garments to be hand-
washed). Color (separate colored garments from whites, wash new colored
garments separately). Delicates (small garments – such as nylon stockings –
and items with hooks – such as bras: insert them in a fabric bag).
Empty the pockets:
Objects such as coins or lighters can damage the washer-dryer and the
drum. Check all buttons.
ACCESSORIES
Contact our Technical Assistance Service to check if accessories are available
for this washer-dryer model.
Technical Service: 1-800-356-0766
OPENING THE PORTHOLE DOOR MANUALLY
In the event that it is not possible to open the porthole door due to a
powercut, and if you wish to remove the laundry, proceed as follows:
1. Remove the plug from the electrical socket.
2. Make sure the water level inside the machine is lower than the door
opening; if it is not, remove excess water using the drain hose, collecting it in
a bucket as indicated in the gure.
3. Using a screwdriver, remove the cover panel on the lower front part of the
washer-dryer (see gure).
4. Unscrew and remove the screw that is holding the tab in place.
5. Pull outwards using the tab as indicated in the figure, until the plastic tie-rod is
freed from its stop position; pull downwards and open the door at the same time.
6. Reposition the panel, making sure the hooks are securely in place before
you push it onto the appliance.
