7. Double check wiring to ensure the connection is correct, close and lock the side panel
as shown below.
8. Finally, connect HUGO’s power cord with the main power outlet. NOTE: HUGO’s rated
input and output is 115 volts, can be fitted to any circuit breaker rated 15A. Ensure all
connects are correct and that the input and output power cord is properly grounded.
9. Turn the front door cam clockwise to “OPEN” and using the supplied KEY turn the lock
counterclockwise to open the front door.
10. If the UPS is used for tankless water heaters and the flow sensor is installed, then plug
in “temp.flow” port in front of the UPS panel. Otherwise, leave this port unplugged.
11. Turn the UPS on via the toggle switch on the left side of the inverter panel. When
turned on, the unit shall chirp once, and the indicator lamp “LINE” will stay lit if utility
power is normal.
12. Indicator lamps on the front panel will display the operational status of the UPS as
shown in Table 1 above. The UPS is also equipped with chirping alerts as shown in
schedule below.
