1
Casing (see 2045 Casing Parts List) 1
2
Impeller, Full 4.5" Diameter 1 5-80X 1
3
Impeller Retainer 1 129-773X
* Impeller O-Ring, FKM
1 V70214
* Impeller O-Ring, EPDM
1 E70214
* Impeller O-Ring, Silicone
1 S75214
* Impeller O-Ring, FFKM
1 K75214
* Impeller O-Ring, PTFE ENCAP.
1 T80214
5
Adapter, 143JM - 184JM Frame, SS 1 122059+ 2
7
3/8 - 16 x 3/4" Hex Screw 4 30-50
8
3/8" Lockwasher 4 43-28
* Casing O-Ring, FKM
1 V70252
* Casing O-Ring, EPDM
1 E70252
* Casing O-Ring, Silicone
1 S75252
* Casing O-Ring, FFKM
1 K75252
* Casing O-Ring, PTFE ENCAP.
1 T80252
10
Backplate 1 1-59X
11
Casing Clamp 1 119-71
12
Key - 3/16" 1 65-3
PL5030-CH1
NOTES:
*
1.
2. Previously supplied as 2 pieces, an adapter and a seal guard; now a single piece.
Trimmed impellers use the same part number and price; specify the diameter
required in 1/8" increments on order.
NOTES
4
9
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
PART
NO.
Recommended Spare Parts - available as kits for standard seals-see seal kit
pages.
Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 57
2045 Pump Parts
