SPX 2085 - Page 65

Waukesha Cherry-Burrell Parts Lists
10/2010 95-03009 Page 65
2105 Pump Parts
1
Casing (see 2105 Casing Parts List) 1
Impeller, 10.5" Dia., 184-215JM Frame SM Bore 1 5-72X 1
Impeller, 10.5" Dia., 254-326JM Frame LG Bore 1 5-70X 1
Impeller Retainer, 184-214JM, SM Bore 1 129-771X
Impeller Retainer, 254-326JM, LG Bore 1 129-772X
* Impeller O-Ring, FKM
1 V70220
* Impeller O-Ring, EPDM
1 E70220
* Impeller O-Ring, Silicone
1 S75220
* Impeller O-Ring, FFKM
1 K75220
* Impeller O-Ring, PTFE ENCAPSULATED
1 T80220
Adapter, 184JM Frame, SS 1 122059+ 2
Adapter, 213-215JM Frame, SS 1 122063+ 2
Adapter, 254-256JM Frame, SS 1 122065+ 2
Adapter, 284-326JM Frame, SS 1 122067+ 2
3/8-16 x 1" Hex Screw, 184JM Frame 4 30-30
1/2-13 x 1-1/4" Hex Screw, 213-256JM Frame 4 30-36X
5/8-11 x 1-1/2" Hex Screw, 284-326JM Frame 4 30-105
3/8" Lockwasher 4 43-28
1/2" Lockwasher 4 43-16
5/8" Lockwasher 4 43-33
* Casing O-Ring, FKM
1 V70450
* Casing O-Ring, EPDM
1 E70450
* Casing O-Ring, Silicone
1 S75450
* Casing O-Ring, FFKM
1 K75450
* Casing O-Ring, PTFE ENCAPSULATED
1 T80450
10
Backplate 1 1-29X
11
Casing Clamp 1 119-223
Key-3/16", 184-215JM, SM Bore 1 65-3
Key-1/4", 254-326JM, LG Bore 1 65-4
PL5030-CH9
NOTES:
*
Recommended Spare Parts - available as kits for standard seals-see seal kit pages.
1.
2. Previously supplied as 2 pieces, an adapter and a seal guard; now a single piece.
Trimmed impellers use the same part number and price; specify the diameter required in 1/8"
increments on order.
NOTES
2
3
4
ITEM
NO.
DESCRIPTION
QTY.
PER
PUMP
PART
NO.
5
12
7
8
9
