MODEL
300 400 500 600
MAINTENANCE KITS
Year 2 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK2-00 HPDMK2-02 HPDMK2-04 HPDMK2-06
Year 3 Maintenance Kit
All the contents of the 2 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK3-00 HPDMK3-02 HPDMK3-04 HPDMK3-06
Year 4 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK4-00 HPDMK4-02 HPDMK4-04 HPDMK4-06
Year 5 Maintenance Kit
All the contents of the 4 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK5-00 HPDMK5-02 HPDMK5-04 HPDMK5-06
Desiccant Kit HPDDES-00 HPDDES-02 HPDDES-04 HPDDES-06
*NOTE: For dryer’s shipped with optional pre-piped F0 or F3 Filter packages, add “-A” for year 2 - 5 kits. (Replacement Prelter and Afterlter elements are not included in Standard Kits.)
REPLACEMENT PARTS
SAFETY
STOCK
DRYER
QTY.
ID# DESCRIPTION
1 Inlet Valve Assembly (V1 & V2)
4010092 4010092 3151877 3151877 1 2
* Solenoid Valve (Sol “A”, “B”) 3203652 3203652 3203652 3203652 1 2
2 Purge Exhaust Valve Assembly (V3 & V4) 4010088 4010088 4010088 4010088 1 2
* Solenoid Valve (Sol “C”, “D”) 3203652 3203652 3203652 3203652 1 2
3 Purge Check Valve (V5 & V6) 3160400 3160400 3160401 3160401 1 2
4 Outlet Check Valve (V7 & V8) 3160400 3160400 3160401 3160401 1 2
6 Purge Heater 3152744 3152739 3152739 3152740 1
7 Heater Temperature Thermocouple (1TC) 3153971 3153971 3153971 3153971 1
8 Heater Overtemperature RTD (RTD3) 3153224 3153224 3153224 3153224 1
9 Chamber RTD (RTD1, RTD2) 3153224 3153224 3153224 3153224 1 2
10 Pressure Relief Valve 7400684 7400684 7400684 7400684 1
11 Chamber Pressure Gauge 4011096 4011096 4011096
4011096 1 2
12 Chamber Pressure Switch (1PS, 2PS) 3149016 3149016 3149016 3149016 1 2
* Chamber Depressurization Pressure Switch (3PS) 3249688 3249688 3249688 3249688 1 1
* Purge Pressure Switch (4PS) 3158360 3158360 3158360 3158360 1 1
14 Pilot Air Filter Element 3158592 3158592 3158592 3158592 1
15 Pilot Air Pressure Regulator 3154237 3154237 3154237 3154237 1
17 Exhaust Mufer 3204478 3130773 3130773 3072056 2
* Exhaust Mufer Replacement Core 3126761 3121200 3121200 3094580 1 2
22 Purge Adjusting Valve 1196180 1196180 1170583 1170583 1
23 Purge Pressure Gauge 4011100 3249310 3249310 3249310 1
26 Purge Pressure Regulator 3204278 3204278 3204278 3204278 1
27 Chamber Blowdown Valve 4009894 4009894 4009894 4009894 2
42 Energy Management Pilot Operated Valve 1274209 1274209 1274209 1274209 1
43 Energy Management Sensor (RTD4/HS1) 3144864 3144864 3144864 3144864 1
* Energy Management Vent Needle Valve 3158747 3158747 3158747 3158747 1
44 Purge Saver 3152713 3152714 3152714 3152715 1
45 Purge Save Inlet Valve Assembly 4010087 3152702 3152702 4010088 1 1
* Purge Save Solenoid (Sol “H”) 3203652 3203652 3203652 3203652 1 1
46 Purge Saver Intake/Filter Silencer 3152725 3152726 3152726 3152727
1
* Inlet Silencer Element 3153682 3051062 3051062 3051062 1 1
58 Dew-point Sensor - Ceramic 3154859 3154859 3154859 3154859 1
* Dryer Controller 7417845 7417845 7417845 7417845 1
* Heater Contactor 3153829 3153829 3153829 3153829 1
* Fuse 1.25A 600V (3FU) 1240671 1240671 1240671 1240671 1 1
* Fuse .5A 600V (1FU, 2FU) 1241118 1241118 1241118 1241118 1 2
* Relay, DPDT 12VDC Coil, 120VAC, 5A (1CR) 3154361 3154361 3154361 3154361 1 1
* Relay, DPDT 120VAC Coil, 120VAC, 10A (4CR) 3158359 3158359 3158359 3158359 1 1
* Temperature Controller 7416897 7416897 7416897 7416897 1
Desiccant Evaluation Kit 3150628 3150628 3150628 3150628
Pre-Filter Assembly HF5-36-12-DGL HF5-40-16-DG HF5-44-20-DG HF5-44-20-DG
Auto-Drain 3152270 3152270 3152270 3152270
Afterlter Assembly HTA400 HTA400 HTA600 HTA600
NOTES:
1. Parts and Maintenance Kits are for standard builds only. Please contact the factory with your dryer serial number for assistance on identifying spare parts and maintenance kits for your specic unit.
2. All quantities for one dryer.
3. ID# correspond to P&ID legend (* Not pictured in diagrams.)
