MODEL
750 900 1050 1300 1500 1800
MAINTENANCE KITS
Year 2 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK2-08 HPDMK2-10 HPDMK2-12 HPDMK2-14 HPDMK2-16 HPDMK2-18
Year 3 Maintenance Kit
All the contents of the 2 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK3-08 HPDMK3-10 HPDMK3-12 HPDMK3-14 HPDMK3-16 HPDMK3-18
Year 4 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK4-08 HPDMK4-10 HPDMK4-12 HPDMK4-14 HPDMK4-16 HPDMK4-18
Year 5 Maintenance Kit
All the contents of the 4 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK5-08 HPDMK5-10 HPDMK5-12 HPDMK5-14 HPDMK5-16 HPDMK5-18
Desiccant Kit HPDDES-08 HPDDES-10 HPDDES-12 HPDDES-14 HPDDES-16 HPDDES-18
*NOTE: For dryer’s shipped with optional pre-piped F0 or F3 Filter packages, add “-A” for year 2 - 5 kits. (Replacement Prelter and Afterlter elements are not included in Standard Kits.)
REPLACEMENT PARTS
SAFETY
STOCK
DRYER
QTY.
ID# DESCRIPTION
1 Inlet Valve Assembly (V1 & V2)
3152393 3152393 3152393 3152393 3152393 3152393 1 2
* Solenoid Valve (Sol “A”, “B”) 3203652 3203652 3203652 3203652 3203652 3203652 1 2
1a Inlet Pilot Operated Valve 3155189 3155189 3155189 3155189 3155189 3155189 1 2
2 Purge Exhaust Valve Assembly (V3 & V4) 3152701 3152701 3152394 3152394 3152394 3152394 1 2
* Solenoid Valve (Sol “C”, “D”) 3203652 3203652 4009880 4009880 4009880 4009880 1 2
3 Purge Check Valve (V5 & V6) 7410577 7410577 7405310 7405310 7405310 7405310 1 2
4 Outlet Check Valve (V7 & V8) 3160059 3160059 3160059 3160059 3160059 3160059 1 2
5 Depressurization Valve (V9 & V10) N/A 4010085 4010085 4010086 4010086
4010086 1 2
* Depress Solenoid Valve (Sol "F", "G") N/A 3203652 3203652 3203652 3203652 3203652 1 2
6 Purge Heater 3152742 3152741 1200773 3152734 3152735 1171782 1
7 Heater Temperature Thermocouple (1TC) 3153971 3153971 3153971 3153971 3153971 3153971 1
8 Heater Overtemperature RTD (RTD3) 3153224 3153224 3153224 3153224 3153224 3153224 1
9 Chamber RTD (RTD1, RTD2) 3153224 3153224 3153224 3153224 3153224 3153224 1 2
10 Pressure Relief Valve 7400684 7400684 7400684 7400684 3100938 3100938 1
11 Chamber Pressure Gauge 4011096 4011096 4011096 4011096 4011096 4011096 1 2
12 Chamber Pressure Switch (1PS, 2PS) 3149016 3149016 3149016 3149016 3149016 3149016 1 2
* Chamber Depressurization Pressure Switch (3PS) 3249688 3249688 3249688 3249688 3249688 3249688 1 1
* Purge Pressure Switch (4PS) 3158360 3158360 3158360 3158360 3158360 3158360 1 1
14 Pilot Air Filter Element 3158592 3158592 3158592 3158592 3158592 3158592 1
15 Pilot Air Pressure Regulator 3154237 3154237 3154237 3154237 3154237 3154237 1
17 Exhaust Mufer 3072056 N/A N/A N/A N/A N/A 2
* Exhaust Mufer Replacement Core 3094580 N/A N/A N/A N/A N/A
2 2
17a Depress Mufer N/A 3071392 3071392 3071392 3090655 3090655 2
* Depress Mufer Replacement Core N/A 3107791 3107791 3107791 3126761 3126761 2 2
22 Purge Adjusting Valve 1170583 1170583 1170583 1170583 1170583 7401510 1
23 Purge Pressure Gauge 3249310 4011100 3249310 3249310 3249310 3249310 1
25 Purge Shut-Off Valve (Sol “E”) N/A 3154250 3154250 3154250 3154250 3154251 1 1
26 Purge Pressure Regulator 3204277 3204278 3204277 3204277 3204277 3204277 1
27 Chamber Blowdown Valve 4009894 4009894 4009894 4009900 4009900 4009900 2
42 Energy Management Pilot Operated Valve 1274209 1274209 1274209 1274209 1274209 1274209 1
43 Energy Management Sensor (RTD4/HS1) 3144864 3144864 3144864 3144864 3144864 3144864 1
* Energy Management Vent Needle Valve 3158747 3158747 3158747 3158747 3158747 3158747 1
44 Purge Saver 3152715 3152715 3152462 3152462 3152462 3152716 1
45 Purge Saver Inlet Valve Assembly 4010088 4010088 3151671 3151671 3151671 3152772 1 1
* Purge Saver Solenoid (Sol “H”) 3203652 3203652 4009880 4009880 4009880 4009880 1 1
46 Purge Saver Intake/Filter Silencer 3152727 3152727 3152461 3152461 3152461 3152728 1
* Inlet Silencer Element
3051062 3051062 1270769 1270769 1270769 1270769 1 1
54 Dew-point Sensor - Ceramic 3154859 3154859 3154859 3154859 3154859 3154859 1
* Controller 7417845 7417845 7417845 7417845 7417845 7417845 1
* Heater Contactor 3153829 3157896 3157896 3157896 3157896 3158650 1
* Fuse 1.25A 600V 1240671 1240671 1240671 1240671 1240671 1240671 1 1
* Fuse .5A 600V 1241118 1241118 1241118 1241118 1241118 1241118 1 2
* Relay, DPDT 12VDC Coil, 120VAC, 5A (1CR) 3154361 3154361 3154361 3154361 3154361 3154361 1 1
* Relay, DPDT 12VDC Coil, 120VAC, 5A (2CR, 3CR) N/A 3154361 3154361 3154361 3154361 3154361 1 2
* Relay, DPDT 120VAC Coil, 120VAC, 10A (4CR) 3158359 3158359 3158359 3158359 3158359 3158359 1 1
* Temperature Controller 7416897 7416897 7416897 7416897 7416897 7416897 1
Desiccant Evaluation Kit 3150628 3150628 3150628 3150628 3150628 3150628
Pre-Filter Assembly HF5-48-20-DG HF5-54-24-G HF5-56-24-G HF5-60-24-G HF5-60-24-G HF5-60-24-G
Auto-Drain 3152270 6000003 6000003 6000003 6000003 6000003
Afterlter Assembly HTA1200 HTA1200 HTA1200 HTA1800 HTA1800 HTA1800
NOTES:
1. Parts and Maintenance Kits are for standard builds only. Please contact the factory with your dryer serial number for assistance on identifying spare parts and maintenance kits for your specic unit.
2. All quantities for one dryer.
3. ID# correspond to P&ID legend (* Not pictured in diagrams.)
4. N/A - Not Applicable to this Model Size
