MODEL
2200 2600 3200
MAINTENANCE KITS
Year 2 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK2-20 HPDMK2-22 HPDMK2-24
Year 3 Maintenance Kit
All the contents of the 2 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK3-20 HPDMK3-22 HPDMK3-24
Year 4 Maintenance Kit Elements*, Mufer, Drain, Desiccant Evaluation Kit HPDMK4-20 HPDMK4-22 HPDMK4-24
Year 5 Maintenance Kit
All the contents of the 4 Year Kit, Pressure
Switches, Valve Repair Kits
HPDMK5-20 HPDMK5-22 HPDMK5-24
Desiccant Kit HPDDES-20 HPDDES-22 HPDDES-24
*NOTE: For dryer’s shipped with optional pre-piped F0 or F3 Filter packages, add “-A” for year 2 - 5 kits. (Replacement Prelter and Afterlter elements are not included in Standard Kits.)
REPLACEMENT PARTS
SAFETY
STOCK
DRYER
QTY.
ID# DESCRIPTION
1 Inlet Valve Assembly (V1 & V2)
3152117 3152117 3152117 1 2
* Solenoid Valve (Sol “A”, “B”) 3203652 3203652 3203652 1 2
1a Inlet Pilot Operated Valve 3155189 3155189 3155189 1 2
2 Purge Exhaust Valve Assembly (V3 & V4) 3152394 3152394 3152093 1 2
* Solenoid Valve (Sol “C”, “D”) 4009880 4009880 4009880 1 2
3 Purge Check Valve (V5 & V6) 3160063 3160063 3160063 1 2
4 Outlet Check Valve (V7 & V8) 3160060 3160060 3160060 1 2
5 Depressurization Valve (V9 & V10) 4010087 4010087 4010087 1 2
* Depress Solenoid Valve (Sol "F", "G") 3203652 3203652 3203652 1 2
6 Purge Heater 3152736 3152738 1217919 1
7 Heater Temperature Thermocouple (1TC) 3153971 3153971 3153971 1
8 Heater Overtemperature RTD (RTD3) 3153224 3153224 3153224 1
9 Chamber RTD (RTD1, RTD2) 3153224 3153224 3153224 1 2
10 Pressure Relief Valve 3100938 3100938 3100938 1
11
Chamber Pressure Gauge 4011096 4011096 4011096 1 2
12 Chamber Pressure Switch (1PS, 2PS) 3149016 3149016 3149016 1 2
* Chamber Depressurization Pressure Switch (3PS) 3249688 3249688 3249688 1 1
* Purge Pressure Switch (4PS) 3158360 3158360 3158360 1 1
14 Pilot Air Filter Element 3158592 3158592 3158592 1
15 Pilot Air Pressure Regulator 3154237 3154237 3154237 1
17a Depress Mufer 3130773 3130773 3130773 2
* Depress Mufer Replacement Core 3121200 3121200 3121200 2 2
22 Purge Adjusting Valve 7401510 7401510 7401510 1
23 Purge Pressure Gauge 4011100 4011100 4011100 1
25 Purge Shut-Off Valve (Sol “E”) 3154251 3154251 3154251 1 1
26 Purge Pressure Regulator 3204278 3204278 3204278 1
27 Chamber Blowdown Valve 4009900 4009900 4009900 2
42 Energy Management Pilot Operated Valve 1274209 1274209 1274209 1
43 Energy Management Sensor (RTD4/HS1) 3144864 3144864 3144864 1
* Energy Management Vent Needle Valve 3158747 3158747 3158747 1
44 Purge Saver 3152716 3152716 3152717 1
45 Purge Saver Inlet Valve Assembly 3152772 3152772 3152394 1 1
* Purge Saver Solenoid (Sol “H”) 4009880 4009880 4009880 1
46 Purge Saver Intake/Filter Silencer 3152728 3152728 3152729 1
* Inlet Silencer Element 1270769 1270769 3153683 1 1
54
Dew-point Sensor - Ceramic 3154859 3154859 3154859 1
* Controller 7417845 7417845 7417845 1
* Heater contactor 3158650 3158650 3158650 1
* Fuse 1.25A 600V (3FU) 1240671 1240671 1240671 1 1
* Fuse .5A 600V (1FU, 2FU) 1241118 1241118 1241118 1 2
* Relay, DPDT 12VDC Coil, 120VAC, 5A (1CR, 2CR, 3CR) 3154361 3154361 3154361 1 3
* Relay, DPDT 120VAC Coil, 120VAC, 10A (4CR) 3158359 3158359 3158359 1 1
* Temperature Controller 7416897 7416897 7416897 1
Desiccant Evaluation Kit 3150628 3150628 3150628
Pre-Filter Assembly HF5-64-4F-G HF5-68-4F-G HF5-72-6F-G
Auto-Drain 6000003 6000003 6000003
Afterlter Assembly HTA2400 HTA3000 HTA4800
NOTES:
1. Parts and Maintenance Kits are for standard builds only. Please contact the factory with your dryer serial number for assistance on identifying spare parts and maintenance kits for your specic unit.
2. All quantities for one dryer.
3. ID# correspond to P&ID legend (* Not pictured in diagrams.)
